Mini Clubman ALL4 (2016)

The full range of optional equipment to increase driving fun, comfort and individuality is also available for the new MINI Clubman ALL4. In addition to modern driver assistance systems such as MINI Head-Up-Display, Driving Assistant, rear view camera and Parking Assistant, this also includes such features as LED headlamps, Comfort Access including non-contact opening of the split doors, electrically adjustable seats for driver and front passenger, a panorama glass roof, What is more, exclusive MINI Yours and John Cooper Works options are available as well as the navigation system Professional including MINI Touch Controller and the complete MINI Journey Mate in-car infotainment program.

Exterior design: classic shooting brake concept in a modern interpretation

The new MINI Clubman introduces a contemporary interpretation of the tradition-steeped shooting brake concept. Its distinctive proportions, unique in the compact segment, are characterised by a dynamically stretched silhouette, a powerful shoulder contour, a long roof line and a sloping rear. With a length of 4 253 millimetres, a width of 1 800 millimetres, a height of 1 441 millimetres and a wheelbase of 2 670 millimetres, it is significantly longer than both its predecessor and the MINI 5 door. The car's distinctive appearance is also accounted for by the horizontal rear lights and a combination applied to a MINI for the first time to reduce aerodynamic drag: Air Curtains - air inlets in the outer areas of the front apron - together with the air outlets known as Air Breathers, which are positioned behind the front wheel arches.

In addition to the circular headlamps set in a chrome frame, the hexagon contour of the radiator grille and the strikingly curved powerdome on the bonnet, typical MINI design features also include the side turn indicator elements known as side scuttles and the black surrounds on the bottom edge of the body. Other equally characteristic aspects are the short overhangs and the large track, which indicate the car's stable stature and - together with a low centre of gravity - contribute to a handling agility that can now be felt more intensely with the all-wheel drive of the new MINI Clubman ALL4.

Exclusive design features are indicative of the powerful engines in the models MINI Cooper S Clubman ALL4 and MINI Cooper SD Clubman ALL4. Their front aprons have a distinctive shaping and there are large cooling air inlets for the brakes. What is more, both models have an additional opening on the bonnet and a chrome rib in the radiator grille bearing a red "S" with a chrome surround. The chrome side scuttles likewise bear an "S" logo. At the rear of the new MINI Cooper S Clubman ALL4 and the new MINI Cooper SD Clubman ALL4, striking features are the aerodynamically optimised bumpers with diffuser element and two widely spaced exhaust tailpipes. In addition, the two all-wheel drive variants of the new MINI Clubman can be identified by their conspicuous "ALL4" inscriptions on the front side panels.

The range of exterior paint finishes available for the MINI Clubman has been expanded at the launch of the all-wheel-drive models to include the new Digital Blue metallic. The roof and exterior mirror caps can be optionally finished in one of the contrasting colours white, silver or black.

Interior: lots of space, distinctive design with sporty flair

Comfortable freedom to move on five fully-fledged seats, versatile space and a distinctive cockpit design - these are the characteristic features of the new MINI Clubman interior, whose high-end ambience is supplemented with a particularly sporty touch in the all-wheel drive models. A clear sign of the more sophisticated character of the MINI Clubman is its exceptionally wide instrument panel with cockpit facia frame. This design feature is also echoed in the door trim panels and centre console. With the new MINI Yours Interior Styles option, the striking door trim design is highlighted by means of indirectly illuminated decorative strips.

The central instrument typical of the brand is integrated particularly harmoniously in the dashboard. A red toggle switch located underneath the central instrument serves as the engine start/stop button. The centre console reaches up to the dashboard and provides space for a storage compartment and two cupholders as well as the switch for the standard electric parking brake and the optional MINI Controller. The standard trim of the new MINI Cooper S Clubman ALL4 and the new MINI Cooper SD Clubman ALL4 also includes sports seats for driver and front passenger as well as a sports leather steering wheel.

The new all-wheel drive system ALL4: fast and precise, compact and efficient

Power transmission to all four wheels now enriches hallmark brand driving fun in the new MINI Clubman ALL4 with the addition of a particularly appealing aspect. The electronically controlled all-wheel drive system distributes drive torque between the front and rear axles as appropriate to each specific situation on the road. This enables highly spirited acceleration and increases agility when taking bends at speed. What is more, ALL4 ensures supreme traction and optimised driving stability in all weathers and road conditions. In this way, the all-wheel drive system underscores the character of the new MINI model in the premium compact segment, which is defined by versatility as well as outstanding everyday practicality and long-distance suitability.

The latest version of the all-wheel drive system ALL4 is particularly compact and weight-optimised in its design. The new construction principle also promotes the efficiency of the MINI Clubman ALL4. The drive power delivered by the engine via the manual or Steptronic transmission in the form of engine speed and torque is initially fed to the front axle differential. An integrated single-stage power take-off bevel gear diverts the power and relays it to a propeller shaft leading to the rear axle. Here power transmission to the rear axle differential is effected in a continuously variable manner via a hang-on clutch, depending on the given situation on the road.

In normal driving situations with active Dynamic Stability Control (DSC), the new MINI Clubman ALL4 uses front-wheel drive as is typical of the brand. This enables a reduction in lost torque of up to 30 per cent in power transmission to the rear axle. If necessary, the hang-on clutch can relay torque to the rear wheels within a fraction of a second by means of an electrohydraulic pump. Fast and precise adaptation to the given situation on the road is possible because the all-wheel drive system is interconnected with the driving dynamics system DSC. Its control unit permanently calculates the ideal power distribution between front and rear wheels. Not only are the wheel rotation speeds and the current longitudinal and lateral acceleration figures taken into account here but also the road speed, accelerator position, engine torque and steering angle as well as the settings of the driving dynamics system and the optional MINI Driving Modes. Based on this data, it is possible to identify early on any risk of drive slip when setting off, in the event of a particularly intense load requirement or during dynamic cornering; in this way it is possible to anticipate and counteract any tendency to lose traction or any oversteering or understeering of the vehicle. Thanks to intelligent control, ALL4 feeds all the power of the engine to the place where it can be converted most effectively and efficiently into driving fun.

The propeller shaft of the ALL4 system is designed as a dual-section tubular shaft. Its joints permit compensation of component movements. The front and rear joint provide the interfaces to the power take-off bevel gear and the hang-on clutch, while it is attached to the body in the area of the central joint. The front section of the propeller shaft also serves to absorb deformation energy in the event of a collision. The efficiency-optimised mode of operation of the ALL4 system is also supported by the hang-on clutch.

This can be operated in a particularly energy-efficient mode when there is no power transmission to the rear wheels. It is instantly activated whenever necessary, however, and directs the appropriate amount of drive torque supplied by the propeller shaft to the rear wheel differential, from where it is transmitted in equal parts to the right and left rear wheel. Differing wheel rotation speeds arising from the specific situation on the road are compensated for in the usual way by means of differentials on both the rear and front axle. Drive slip is suppressed by the driving dynamics system DSC by means of selective braking on individual wheels.

Taking the form of an electronic locking function for the front axle differential, the standard Electronic Differential Lock Control (EDLC) optimises traction when accelerating out of bends by means of selective braking. In DSC Off mode, this prevents spinning of the front wheel on the inside of the bend and transmits drive power to the outer front wheel instead. The Performance Control function is another standard feature that helps enhance agility in the MINI Cooper S Clubman ALL4 and the MINI Cooper SD Clubman ALL4. It supports precise steering into bends even before the threshold range is reached and regardless of the DSC mode selected. Braking on the two wheels on the inside of the bend impacts positively on the car's self-steering response and suppresses the risk of understeering. Other functions of the driving dynamics system DSC include the anti-lock brake system ABS, Electronic Brakeforce Distribution (EBD), Cornering Brake Control (CBD), the braking and drive-off assistant, the brake dry function and Fading Brake Support. It is also possible to activate the DTC (Dynamic Traction Control) mode at the press of a button, permitting controlled slip and thereby facilitating set-off on loose sand or in deep snow.

Petrol and diesel engines with MINI TwinPower Turbo Technology: a lot of power efficiently distributed over four wheels

The power distributed as needed by the all-wheel drive system ALL4 between the front and rear axle is produced by highly powerful 4-cylinder engines of the latest generation with MINI TwinPower Turbo Technology. These make for sporty driving properties and are also able to demonstrate their qualities in the area of efficiency in the new MINI Clubman ALL4. Thanks to the optimised weight and efficient mode of operation of the new all-wheel drive system, the boost in terms of driving fun and supreme forward thrust only involves a very slight increase in fuel consumption and exhaust emissions as compared to the respective models with front-wheel drive.

With a peak output of 141 kW/192 hp, the 2.0-litre petrol engine in the new MINI Cooper S Clubman ALL4 is the most powerful engine in the compact model's portfolio. Its technology package comprises turbocharging, petrol direct injection with centrally placed injectors, fully variable valve control in the form of VALVETRONIC as patented by the BMW Group and variable camshaft control on the intake and exhaust side (double VANOS). It mobilises a maximum torque of 280 Newton metres at 1 250 rpm, and this can even be briefly increased to 300 Newton metres by means of the overboost function.

With the standard 6-speed manual transmission, the new MINI Cooper S Clubman ALL4 accelerates in 7.0 seconds from standing to 100 km/h, while in conjunction with the optional 8-speed Steptronic transmission the standard spurt takes just 6.9 seconds. The top speed is 225 km/h in each case. These figures are combined with an average fuel consumption of 7.0 to 6.9 litres (automatic: 6.4 - 6.3 litres) per 100 kilometres and CO2 emissions of 162 to 159 grams per kilometre (149 - 146 g/km; EU test cycle figures, dependent on tyre format selected).

A turbocharging system with variable turbine geometry and common rail direct injection of the latest generation operating at a pressure of up to 2 000 bar helps the likewise 2.0-litre diesel engine in the new MINI Cooper SD Clubman ALL4 achieve superb pulling power as well as exemplary fuel consumption figures and emissions. The power unit generates a peak output of 140 kW/190 hp and puts its maximum torque of 400 Newton metres on line at just 1 750 rpm. The new MINI Cooper SD Clubman ALL4 combines the most powerful diesel engine ever installed in a model of the brand as standard with the 8-speed Steptronic transmission. This enables a sprint from standing to 100 km/h in 7.2 seconds. The top speed is 222 km/h. These sporty figures are combined with an average fuel consumption of 4.9 to 4.8 litres per 100 kilometres and a CO2 emissions level of 129 to 126 grams per kilometre (EU test cycle figures, dependent on tyre format selected).

Innovative transmissions for increased driving fun and efficiency

The transmissions available for the new MINI Clubman ALL4 have also been newly developed for the current model generation of the brand. The 6-speed manual transmission is characterised by low weight, high internal efficiency and shift comfort optimised by means of carbon friction linings for the synchroniser rings. A gear sensor also enables active engine speed adaptation for especially sporty shifting when accelerating and increased comfort when shifting down.

With its broader gear spread and smaller engine speed steps, the 8-speed Steptronic transmission provides an especially favourable basis for efficient, comfortable and sporty driving. An 8-speed Steptronic sports transmission is optionally available for the new MINI Cooper S Clubman ALL4 and the new MINI Cooper SD Clubman ALL4 that offers even shorter shift times and is operated in manual mode by means of shift paddles on the steering wheel. It also has a Launch Control function for traction-optimised acceleration with maximum dynamic performance from standing.

Both automatic variants have a transmission control system that is able to draw on navigation data for the purpose of gear and shift point selection. This means that in cars fitted with a navigation system, shift control is also based on the route profile.

Typical MINI suspension technology, characteristic go-kart feeling

In conjunction with all-wheel drive, too, the high-quality suspension technology with a single joint strut axle at the front and a multilink rear axle provides an ideal basis for the agile handling known as the go-kart feeling. The large track width and long wheelbase of the MINI Clubman ALL4 benefit the model-specific interpretation of this construction principle. The new development of all front axle parts has resulted in an optimisation of kinematics as well as component stiffness and weight. The particularly stiff wheel suspension on the rear axle also enhances the agile handling properties of the MINI Clubman. Dynamic Damper Control is available as an optional extra. This allows the damper program map to be adjusted via MINI Driving Modes.

The new MINI Clubman ALL4 comes as standard with the speed-related Servotronic steering support for the electromechanical power steering. Both all-wheel drive model variants come off the production line with 17-inch light alloy wheels. The range of special equipment features includes additional light alloy wheels sized 17 to 19 inches.

A complete set of safety features, innovative driver assistance systems, intelligent connectivity

In addition to the torsionally stiff, rigid and also weight-optimised body structure, a complete set of standard safety features also contributes to the outstanding occupant protection of the new MINI Clubman ALL4. This comprises six airbags, 3-point automatic belts on all seats including belt tensioners and adaptive belt force limiters at the front as well as ISOFIX child seat mountings at the rear. A tyre pressure display for each individual wheel is also included as standard. Meanwhile, impact absorbers and precisely defined deformation elements ensure optimised pedestrian protection.

The driver assistance systems offered for the new MINI Clubman ALL4 serve to increase both safety and comfort. The MINI Head-Up Display which extends from above the steering column promotes concentration on the road. In addition to the cruise control with brake function, the Driving Assistant system is also available. This comprises not just camera-based active cruise control as well as collision and pedestrian warning with initial brake function but also high beam assistant and road sign detection. Additional options include the Parking Assistant and rear view camera.

The unique MINI Connected in-car infotainment program is also available in its entirety for the new MINI Clubman ALL4. The option MINI Connected is available in conjunction with the Radio MINI Visual Boost or a navigation system. It offers extensive integration of smartphones in the car, allowing the use of internet-based services in the areas of infotainment, communication and driving experience by means of apps. Operation is intuitive and reflects hallmark brand style, using the MINI Controller in the centre console and the colour display in the central instrument.

The features of the MINI navigation system Professional include an 8.8-inch version of the on-board computer and the MINI Touch Controller with touch-sensitive surface.

The current version of the MINI Connected App comprises new and exclusive functions to increase comfort and driving fun. The online search function makes it easier to find addresses. The applications Sports Instruments and Force Meter can be used to show information on the central instrument display such as the level of current engine power and torque in use and longitudinal and transverse acceleration. The new function Streetwise provides the driver with tips for an optimum route even before the journey gets underway. The MINI Connected XL option available in combination with the MINI navigation system Professional also comprises the Journey Mate function including innovative functions for trip preparation and support as well as Real Time Traffic Radar with highly precise, up-to-date traffic information. The new MINI Clubman ALL4 can also be equipped with a SIM card which is permanently fitted in the car. This means that Intelligent Emergency Call with automatic detection of vehicle location and accident severity is available, as well as MINI TeleServices.
