BMW M6 (2005)

The two five-cylinder banks in the V10 are arranged at an angle of 90° in order to optimize the standard of vibration control and motoring comfort offered by full mass compensation on the crankdrive. Taking the substantial forces of the combustion process, high engine speeds and vibrations into account, the crankcase comes in bedplate design. The extremely stiff crankshaft, in turn, runs in six bearings.

Variable dual-VANOS camshaft control ensures an optimum cylinder charge cycle in the interest of extremely fast valve timing. On the road this means even more performance, an improved torque curve, optimum responsiveness, lower fuel consumption, and emissions reduced to a minimum. Again reflecting the typical features of motorsport, each cylinder comes with its own throttle butterfly masterminded fully electronically for each row of cylinders.

Twin-chamber exhaust system made of stainless steel.

Made of stainless steel without any connecting seams, the exhaust system comes in twin-chamber configuration all the way to the silencers, before exhaust emissions leave the car through the four tailpipes so characteristic of every BMW M Car. It almost goes without saying that exhaust emissions meet the European EU4 and, respectively, the US LEV2 standards. The BMW M6 stands out from the M5 also through its even more powerful and sporting sound.

This outstanding performance and emission management is ensured and masterminded by the central engine management unit featuring the most powerful processors currently to be found in any car anywhere, since the demands made of the management system are obviously particularly stringent due to the very high engine speed and the sum total of all control and management functions.

A particular highlight of the engine control unit is ionic current technology serving to detect any tendency of the engine to knock, misfire and suffer mis-combustion. This intelligent control unit is able to sense any tendency to knock via the spark plug in each cylinder, checking the correct ignition setting and recognizing any tendency to misfire and thus allowing the engine to run as closely as possible to its theoretical limits, developing optimum power and performance in the process. The spark plug serves both as an actuator for the ignition and as a sensor observing the combustion process.

Seven-speed SMG transmission conveying M Power to the road.

BMW's seven-speed SMG transmission will be the only one offered in the new BMW M6. This gearbox from BMW M is indeed the world's only sequential transmission with seven gears and Drivelogic. With qualities even greater than on a six-speed SMG gearbox, this transmission allows manual selection of gears with extremely short gearshift times as well as comfortable cruising qualities thanks to the automatic gear selection function. And at the same time the additional gear keeps the increments between engine speed and torque even smaller, ensuring an absolutely smooth process of one gear "flowing" into the other.

The driver shifts gears in the SMG transmission either from the selector lever or via paddles in the steering wheel. Compared with the conventional SMG transmission, the new generation of SMG technology performs the entire gearshift process 20 per cent faster, gears merging directly into one another.

As a result, any interruption of the flow of power inevitable when shifting gears now becomes hardly perceptible. The BMW M6 accelerates virtually without the slightest jolt or interruption from a standstill all the way to top speed.

Drivelogic: The driver determines how SMG shifts gears.

Featuring its special Drivelogic function, SMG on the BMW M6 offers the driver a total of 11 gearshift options allowing him to individually adjust the gearshift characteristics of the SMG transmission to his personal style of motoring.

Six of these driving programs come in the sequential manual function (S-mode), ranging from smooth but dynamic all the way to race track crisp. Driving in the S-mode, the driver shifts gears manually. But thanks to the launch control function SMG Drivelogic shifts gears automatically shortly before the engine reaches its maximum speed, ensuring an optimum gearshift process with optimum spin control all the way to the top speed of the BMW M6.

In the automatic shift mode (Drive = D-mode), the transmission shifts the seven gears automatically as a function of the driving program currently in use, the driving situation, road speed, and the position of the gas pedal.

SMG for even greater safety and motoring comfort.

Seven-speed SMG supports the driver not only in achieving and enjoying the highest standard of performance comparable to genuine motorsport. It also comes with many safety features opening up the clutch within fractions of a second in a critical situation - for example when shifting down on a slippery surface - in order to keep the car stable and free of excessive engine forces acting on the drive wheels. A further special function is hill detection, which adjusts the gearshift points on uphill and downhill grades. Driving uphill, this avoids the common phenomenon of the gears constantly shifting up and down ("pendulum gearshift"); driving downhill the hill detection mode holds lower gears in mesh longer than usual in order to capitalize on the engine's braking effect.

Last but not least, SMG also enhances the particular sound effect of the V10 power unit: To quote a specialist commenting on this special sound, that "brief, roaring rumble" is simply fantastic when the electronic engine control unit "blips" the throttle between gears when shifting down.

Maximum driving pleasure.

Interaction of the V10 power unit and seven-speed SMG gives the driver of the BMW M6 Coupe driving pleasure of the highest caliber: Acceleration from 0-100 km/h (62 mph) comes in 4.6 seconds and the BMW M6 reaches 200 km/h or 124 mph in just about 14 seconds. Then, at a speed of 250 km/h or 155 mph, the electronic speed governor ends the car's irresistible surge of power, while the speedometer gives you an idea where the engine would take you without such electronic speed control: the speedometer goes all the way to 330 km/h or 205 mph.

Lapping the Northern Circuit of Nürburgring in 8 minutes.

The world-famous Nordschleife, the Northern Circuit of the legendary Nürburgring Race Track, is the perfect benchmark for measuring driving dynamics. For it is here, on the world's most demanding race track, that the exceptional stand out from the mediocre in terms of driving dynamics. Nowhere else is the interaction of all a car's components as clear as here, when driving to the absolute limit. Lapping the Northern Circuit in around 8 minutes, the BMW M6 easily matches the most thoroughbred sports cars, clearly beating the competition.

M Suspension: The icing on the cake of the BMW 6-Series.

Lap times of this kind clearly bear testimony to the BMW M6's driving qualities. Which is actually no surprise, considering that the chassis and suspension already outstanding on the BMW 6-Series as such. The modern assistance systems have been specially adapted on the BMW M6 for truly unparalleled M Performance. Compared with the M5, in turn, the wheelbase is shorter and the car comes with a lower centre of gravity for extra agility on the road. In terms of both chassis equipment and set-up, the BMW M6 is therefore a unique car in every respect.

Variable M Differential Lock.

The variable, speed-sensing M Differential Lock gives the BMW M6 superior driving stability and optimum traction particularly when accelerating out of a bend. Even in very demanding driving situations, the differential offers crucial advantages in terms of traction, for example with the drive wheels running on very different surfaces with a wide range of different frictional coefficients.

A further advantage - the locking action immediately builds up when necessary to compensate for any difference in speed between the drive wheels, thus ensuring smooth and powerful drive forces at all times.

DSC with two dynamic driving programs available on demand.

The BMW M6 boasts a brand-new generation of Dynamic Stability Control. With the first stage of DSC being conceived for maximum driving safety, the M Dynamic mode, as on the M5, is tailored to the sporting driver. And pressing a button on the selector lever cover, the driver is able to switch off DSC whenever he wishes.

EDC: From firm and taut all the way to comfortable and extra-smooth.

EDC Electronic Damper Control on the BMW M6 offers the driver the choice of three programs available on demand: Comfort, Normal, and Sports, with the car's chassis and suspension ranging from sporting and taut all the way to - relatively - smooth and comfortable. The driver operates EDC via the MDrive button on the steering wheel or the push button next to the SMG selector lever.

High-performance brakes like in motorsport.

Reflecting its truly outstanding power and performance, the BMW M6 naturally features extra-large high-performance brakes complete with cross-drilled extra-low-weight compound brake discs. The double-piston swing calipers are made of aluminum and are optimized for both weight and stiffness. Applying the brakes from a speed of 100 km/h (62 mph), the driver of the BMW M6 comes to a standstill after just 36 meters and takes less than 140 meters to reach a stop from a speed of 200 km/h (124 mph).

High-performance athlete in a beautiful body.

With the BMW 6-Series already acknowledged as a strikingly beautiful car, the BMW M6 enhances this impression to an even higher standard. Special design features making this unique Coupe look even more powerful and dynamic, while remaining discreet and unpretentious.

The most eye-catching feature is the truly impressive front air dam. And like all design features on a BMW M Car, this particular element focuses once again primarily on its specific function: The V10 power unit requires roughly twice as much cooling air as the V8 in the BMW 645Ci. Large secondary intake openings to the left and right of the front air dam thus give the engine of the BMW M6 even more air to breathe and cool the brakes at the same time. Through their design alone, finally, these air openings accentuate the sporting character of the car.

Lightweight engineering and beautiful design in perfect harmony.

Beneath the doors the side-sills powerfully contoured for aerodynamic reasons again emphasize the dynamic impression of this sports coupe. At the same time the side-sills stretch the car for an even sleeker look, making the BMW M6 even lower and more dynamic in its appearance.

The 19-inch forged aluminum wheels developed especially for the BMW M6, together with their five filigree double spokes, are extremely light and provide a very good view of the large brake discs. Compared with comparable wheels, the weight saving is 1.8 kilos per wheel.

The M model logo in the ornamental slats at the side tells the connoisseur right away that this car is one of the outstanding athletes within the BMW M Family. And like on all M Models, the exterior mirrors come in their very own, sporting look.

The rear air dam with its characteristic diffuser opening again serves first and foremost to provide an aerodynamic function. But at the same time it adds an even more sporting look to the car. The particular design of the diffuser improves the flow of air along the underside and reduces lift forces. The four tailpipes on the twin-chamber exhaust system, bordering the diffuser opening in pairs on either side, are one of the signs of distinction so typical of a BMW M Car.

First-ever carbon-fiber roof in series production.

The first car to feature a roof made of carbon-fiber was the BMW M3 CSL. Now, following that special model built in small, strictly limited series, BMW M GmbH is introducing a carbon-fiber roof on the BMW M6 Coupe, thus raising this concept of intelligent lightweight technology to a new dimension in series production.

Offering the same stability and crash safety as a steel roof, this carbon-fiber material derived from motorsport is significantly lighter than aluminum, let alone steel. The result is a significant reduction in weight and mass lowering the car's center of gravity.

Inside, the BMW M6 stands out from the "basic" model also through its even more sophisticated Merino leather upholstery with a choice of three different colors or - at extra cost - with full leather upholstery leaving absolutely nothing to be desired.

A sports car for everyday motoring.

Despite its simply staggering performance, the BMW M6 does not make any compromises in terms of adequate roominess as well as active and passive safety of the highest standard. Even the level of motoring comfort is virtually the same as in the "regular" model. And when it comes to both fuel economy and environmental compatibility, the BMW M6 again lives up the exemplary standard of all BMWs.

Technical Specifications

• Body
  • No. of doors: 2
  • No. of seats: 2+2
  • Length: 4,871 mm
  • Width: 1,855 mm
  • Height: 1,377 mm
  • Wheelbase: 2,781 mm
  • Track
    • Front: 1,567 mm
    • Rear: 1,584 mm
  • Turning circle: 12.5 m
  • Fuel tank capacity: 70 l
  • Weight unladen (EU): 1,710 kg
  • Max. load (DIN): 415 kg
  • Max. permissible weight (DIN): 2,200 kg
  • Luggage comp. capacity: 450 l
• Engine
  • Type: V10
  • Engine management: MS S65
  • Displacement: 4,999 cc
  • Bore: 92.0 mm
  • Stroke: 75.2 mm
  • Compression: 12.0:1
  • Fuel grade: 95-98 (RON)
  • Max. power: 507 bhp (373 kW) @ 7,750 rpm
  • Max. torque: 520 Nm @ 6,100 rpm
• Chassis
  • Front suspension: Double-joint thrust-rod spring strut axle in aluminium; compensation of transverse forces; anti-dive.
  • Rear suspension: Integral axle (aluminium), wheel suspension with special effect anti-squat/anti-dive
  • Brakes
    • Front: Single-piston floating-caliper disc brakes; 348 mm, vented
    • Rear: Single-piston floating-caliper disc brakes; 345 mm, vented
  • Driving stability system: ABS, DSC, CBC
  • Steering: Rack-and-pinion, power-assisted
  • Type of transmission: SMG III
  • Tyre
    • Front: 255/40 ZR19
    • Rear: 285/35 ZR19
  • Wheels
    • Front: 8,5J x 19 EH 2 IS 12 Alu
    • Rear: 9,5J x 19 EH 2 IS 28 Alu
• Performance
  • Power to weight ratio (DIN): 4.6 kg/kW
  • Output per litre: 74.6 l/kW
  • Acceleration
    • 0-100 km/h (0-62 mph): 4.6 s
    • 80-120 km/h (50-75 mph): 4.4/5.8 s (4th/5th gear)
  • Top speed: 250 km/h (155 mph) [electronically limited]
  • Fuel consumption (EU cycle)
    • urban: 22.7 l/100 km
    • extra-urban: 10.2 l/100 km
    • combined: 14.8 l/100 km
  • CO2: 357 g/km
